JL-CT20 SONY IMX307 Sensor 1080P AHD Rear Car Camera 170 Degree View Angle Color Image in Night Vision
Vehicle CameraJOINLOG,JL-CT20,SONY IMX307 Sensor 1080P AHD Rear Car Camera 170 Degree View Angle Color Image in Night Vision
Vehicle Camera
- Resolution： 1080P
- Mode： NTSC; PAL Optional
- Lens： 1.8MM
- Night Vision： NO IR; Full color
- Parameters
- Resolution： 1080P
- Mode： NTSC; PAL Optional
- Lens： 1.8MM
- Night Vision： NO IR; Full color
Product Features
- 1/3” CMOS image sensor;
- 1080P AHD high-resolution;
- Metal-cased mini housing with standard fixed lens;
- 1.4mm lens optional, 170 degree view angle;
- Easy installation to ceiling or wall;
- Support 12V DC ±10%,Low power consumption.
Product Specification
| Model | JL-CS80 |
| Image Sensor | 1/3” CMOS SONY IMX307 |
| TV System | PAL/NTSC |
| Horizontal Resolution | 1080P |
| Lens optional | 1.4 mm |
| Min illumination | 0.1 Lux at F1.2 (Infrared LED On) |
| S/N Ratio | More than 48 dB(AGC Off) |
| WDR | Support |
| Audio fuction | N/A |
| horizontal angle of view | 170° (D) |
| Tilt Adjusting | 0-60 Degree |
| Power Supply | 12V DC ±10%, 210mA |
| Net Weight | 150 g |
| Weatherproof/Water Proof | IP68 |
| Operational Temperature | -40 ~ +60 ° C |
| Operational humidity | 20 ~ 80% |
| vedio interface | Aircraft Round Connector Plug |
